Page 100: Electrical data – w2w2 continued
SmartCool
TM
- D
Precision Air Conditioning
100
Precision Air Conditioning
Installation, Maintenance and Commissioning Manual :6877419 02/2013
Electrical Data – W2W2 Continued
SCD31D100-W2W2
SC31D120-W2W2
SC31D130-W2W2
Standard Dry Cooler Match
2 x DR70
2 x DR95
2 x DR95
Unit Data - W2W2
(1)
Nominal Run Amps
A
102.7
113.5
118.1
Maximum Start Amps
A
216.0
215.8
226.6
Recommended Mains Fuse Size
A
125
125
125
Max Mains Incoming Cable Size
mm²
70
70
70
Mains Supply
V
400V / 3PH + N / 50Hz
Control circuit
VAC
24
24
24
Unit Data Cooling Only – W2W2
Nominal Run Amps
A
86.5
97.3
101.9
Maximum Start Amps
A
199.6
210.4
245.7
Recommended Mains Fuse Size
A
100
125
125
Evaporator Fan Motor - Per Fan
Motor Type
EC
EC
EC
Quantity x Motor Size
(2)
kW
3 x 3.1
3 x 3.1
3 x 3.1
Full Load Amps
A
4.8
4.8
4.8
Locked Rotor Amps
A
4.8
4.8
4.8
Compressor 1 , Circuit 1 & 2
(3)
Motor Size
kW
7.19
9.46
9.46
Nominal Run Amps
A
12.9
16.9
16.9
Locked Rotor Amps
A
92
130
130
Type of Start
Direct On Line
Compressor 2, Circuit 1 & 2
(3)
Motor Size
kW
9.5
9.5
10.9
Nominal Run Amps
A
16.9
16.9
19.2
Locked Rotor Amps
A
130
130
163
Type of Start
Direct On Line
Standard Dry Cooler Match - AC Motor Per Fan
Quantity x Motor Size
kW
3 x 0.6
4 x 0.88
4 x 0.88
Full Load Amps
A
2.62
1.65
1.65
OPTIONAL EXTRAS
Electric Heating
Stage of Reheat
3
3
3
Number of Elements
9
9
9
Rating (Total)
kW
31.5
31.5
31.5
Current Per Phase
A
45.47
45.47
45.47
Humidifier
Capacity
kg/hr
15
15
15
Rating
kW
11.25
11.25
11.25
Full Load Amps
A
16.2
16.2
16.2
Standard Size Fan Motor - EC Motor - Per Fan
Quantity x Motor Size
kW
N/A
N/A
N/A
Full Load Amps
A
N/A
N/A
N/A
Locked Rotor Amps
A
N/A
N/A
N/A
Larger Size Motor - EC Motor - Per Fan
Quantity x Motor Size
kW
N/A
N/A
N/A
Full Load Amps
A
N/A
N/A
N/A
Locked Rotor Amps
A
N/A
N/A
N/A
Standard Dry Cooler Match - EC Motor-Per Fan
Quantity x Motor Size
kW
3 x 0.73
4 x 1.68
4 x 1.68
Full Load Amps
A
3.3
2.6
2.6
SCAF Dry Cooler Match – Motor – Per Fan
Quantity x Motor Size
kW
3 x 1.4
4 x 1.94
4 x 1.94
Full Load Amps
A
6
3.4
3.4
(1) Values given for full function units with standard selections for heating, humidification, supply air fans and matched condenser
at 7°C evaporating and 54.4°C condensing
(2) Stated motor power is based on maximum electrical power absorbed
(3) Values are per compressor
