Waterside pressure drop - C0C0
0
20
40
60
80
100
120
140
160
180
200
0
1
2
3
4
5
6
Flow Rate (l/s)
P
ress
u
re
D
ro
p
(
kP
a)
1
2
3
Key
1
SC19D033 - 045
2
SC25D045 - 055
3
SC31D055 - 075
(1)
Includes coil, 3 port valve and pipework.
(2)
To calculate 3 port valve pressure drop:
DP valve =
2
ч
ш
ц
з
и
ж
M
Q
where
DP = Pressure Drop in kPa, Q = Water Flow Rate in l/s and M =
ч
ш
ц
з
и
ж
36
Kv
(3)
Fluid 100% water.
M Values
Model Sizes
SC19D33-45
SC25D45-55
SC31D55-75
Chilled Water “M” Valves
1.11
0.8
0.8
C
0
C0
