Installation, Maintenance and Commissioning Manual :6877419 02/2013
Electrical Data - C0C0
SC19D033-C0C0-0
SC19D038-C0C0-0
SC19D045-C0C0-0
Unit Data Full Function C0C0
(1)
Nominal Run Amps
A
69.3
69.3
69.3
Maximum Start Amps
A
69.3
69.3
69.3
Recommended Mains Fuse Size
A
80
80
80
Max Mains Incoming Cable Size
mm²
35
35
35
Mains Supply
V
400V / 3PH + N / 50Hz
Control circuit
VAC
24
24
24
Unit Data Cooling Only C0C0
Nominal Run Amps
A
7.6
7.6
7.6
Maximum Start Amps
A
7.6
7.6
7.6
Recommended Mains Fuse Size
A
10
10
10
Evaporator Fan - Motor - Per Fan
Motor Type
EC
EC
EC
Quantity x Motor Size
(2)
kW
2 x 2.2
2 x 2.2
2 x 2.2
Full Load Amps
A
3.3
3.3
3.3
Locked Rotor Amps
A
3.3
3.3
3.3
OPTIONAL EXTRAS
Electric Heating
Stage of Reheat
3
3
3
Number of Elements
9
9
9
Rating (Total)
kW
31.5
31.5
31.5
Current Per Phase
A
45.47
45.47
45.47
Humidifier
Capacity
kg/hr
15
15
15
Rating
kW
11.25
11.25
11.25
Full Load Amps
A
16.2
16.2
16.2
First upgrade EC Motor - Per Fan
Quantity x Motor Size
kW
2 x 3.1
2 x 3.1
2 x 3.1
Full Load Amps
A
4.8
4.8
4.8
Locked Rotor Amps
A
4.8
4.8
4.8
Second upgrade EC Motor - Per Fan
Quantity x Motor Size
kW
N/A
N/A
N/A
Full Load Amps
A
N/A
N/A
N/A
Locked Rotor Amps
A
N/A
N/A
N/A
(1) Values given for function units with standard selections for heating, humidification, supply air fans.
(2) Stated motor power is based on maximum electrical power absorbed
SC25D045-C0C0-0
SC25D50-C0C0-0
SC25D55-C0C0-0
Unit Data Full Function – C0C0
(1)
Nominal Run Amps
A
77.7
77.7
77.7
Maximum Start Amps
A
115.2
115.2
115.2
Recommended Mains Fuse Size
A
100
100
100
Max Mains Incoming Cable Size
mm²
35
35
35
Mains Supply
V
400V / 3PH + N / 50Hz
Control circuit
VAC
24
24
24
Unit Data Cooling Only C0C0
Nominal Run Amps
A
16.00
16.00
16.00
Maximum Start Amps
A
53.5
53.5
53.5
Recommended Mains Fuse Size
A
25
25
25
Evaporator Fan - Motor - Per Fan
Motor Type
AC
AC
AC
Quantity x Motor Size
(2)
kW
3 x 2.38
3 x 2.38
3 x 2.38
Full Load Amps
A
5
5
5
Locked Rotor Amps
A
17.5
17.5
17.5
OPTIONAL EXTRAS
Electric Heating
Stage of Reheat
3
3
3
Number of Elements
9
9
9
Rating (Total)
kW
31.5
31.5
31.5
Current Per Phase
A
45.
45.5
45.5
Humidifier
Capacity
Kg/hr
15
15
15
Rating
A
11.25
11.25
11.25
Full Load Amps
A
16.2
16.2
16.2
First upgrade Fan Motor - EC Motor - Per Fan
Backwards Curved, Centrifugal direct drive
Quantity x Motor Size
kW
3 x 2.2
3 x 2.2
3 x 2.2
Full Load Amps
A
3.3
3.3
3.3
Locked Rotor Amps
A
3.3
3.3
3.3
Second upgrade Motor - EC Motor - Per Fan
Backwards Curved, Centrifugal direct drive
Quantity x Motor Size
kW
3 x 3.1
3 x 3.1
3 x 3.1
Full Load Amps
A
4.8
4.8
4.8
Locked Rotor Amps
A
4.8
4.8
4.8
(1) Values given for function units with standard selections for heating, humidification, supply air fans.
(2) Stated motor power is based on maximum electrical power absorbed
