Smartcool, Precision air conditioning, X2 c0 – Airedale SmartCool 11-233kW User Manual
Page 78: Mechanical data –x2c0
SmartCool
TM
- D
Precision Air Conditioning
78
Precision Air Conditioning
Installation, Maintenance and Commissioning Manual :6877419 02/2013
Mechanical Data –X2C0
SC19D033-X2C0-0
SC19D038-X2C0-0
SC19D045-X2C0-0
Standard Condenser Match -
1 x CR50
1 x CR65
1 x CR65
Capacity
Nom Cooling (Gross) – X2
(1)
kW
28.9
36.4
41.3
Nom Cooling (Gross) – C0
(2)
kW
61.6
67.9
74.4
Capacity Steps
2
2
2
Fan Gain
(7)
kW
0.66
1.0
1.7
Dimensions - W x D x H
mm
1985 x 890 x 1980
1985 x 890 x 1980
1985 x 890 x 1980
Weight - Machine / Operating
(3)
kg
820 / 860
820 / 860
820 / 860
Construction
Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint - Black Grey (RAL 7021)
Material/Colour
Frame: Anodised Aluminium Frame with Black Nylon Corners
Evaporator – X2
Rifled Copper Tube/ Turbulated Hydrophilic Coated Aluminium Fins
Cooling / Dehum Stages
2/1
2/1
2/1
Cooling Coil – C0
Copper Tube / Turbulated Hydrophilic Coated Aluminium Fins
Cooling / Dehum Stages
1(Modulated)/ 1
Water Volume
l
27.4
27.4
27.4
Water flow rate
l/s
2.44
2.72
3.14
Pressure drop
kPa
23.33
27.8
35.01
Fan Motor
Backwards Curved, Centrifugal direct drive
Motor Type
EC
EC
EC
Quantity x Motor Size
kW
2 x 2.2
2 x 2.2
2 x 2.2
Speed @ 25Pa / Maximum ESP
964 / 1360
1117 / 1360
1340 / 1360
Maximum ESP
Pa
438
302
49
Nominal Airflow
m³/s
3.7
4.3
5.1
Compressor - Scroll
Configuration
Dual Cool - Circuit 1 Tandem Compressors (Refrigeration) / Circuit 2 Chilled water
Quantity
2
2
2
Oil Charge Volume
l
2 x 1.57
2 x 1.57
2 x 1.57
Oil Type
Polyolvinyl
Refrigeration
Single Circuit
Refrigeration Control & Type
Thermostatic Expansion Valve (Optional EEV)
Refrigeration Type
(4)
R410A
Holding Charge
Inert Gas
Charge (Total)
kg
9.2
14.4
14.4
Connections
Liquid (Sweat) – X2
in
1/2
5/8
5/8
Discharge (Sweat) – X2
in
7/8
7/8
7/8
Water Inlet / Outlet – C0
mm
35
35
35
Condensate Drain Hose
mm
22
22
22
Filtration
Disposable to BS EN 779-G4-600
Quantity
3
3
3
OPTIONAL EXTRAS
Hot Gas Reheat - X
Nom Heating (Gross)
(5)
kW
8.3
9.2
9.7
Electric Heating (Total)
kW
21
21
21
Humidifier
Capacity
kg/hr
8
8
8
Feed/Drain
3/4" BSPF Braided flexible hose / 19mm hose connection
Condensate Pump
Head
m
10.8
10.8
10.8
Flow
l/m
5
5
5
Drain
10mm Stainless Steel Stub Connection
First upgrade Fan Motor - EC Motor
Centrifugal direct drive
Quantity x Motor Size
kW
2 x 3.1
2 x 3.1
2 x 3.1
Speed @ 25Pa / Maximum ESP
RPM
986 / 1520
1145 / 1520
1340 / 1520
Maximum ESP
Pa
589
453
216
Fan Gain
(7)
kW
0.65
1.03
1.73
Second upgrade Fan Motor - EC Motor
Centrifugal direct drive
Quantity x Motor Size
kW
N/A
N/A
N/A
Speed @ 25Pa / Maximum ESP
rpm
N/A
N/A
N/A
Maximum ESP
Pa
N/A
N/A
N/A
Fan Gain
(7)
kW
N/A
N/A
N/A
Low Pressure Hot Water
Copper Tube / Aluminium Fin
Capacity Gross
(6)
kW
22.2
24.5
26.0
Water Flow (Nominal)
l/s
0.49
0.54
0.58
Pressure drop
kPa
9.4
9.7
10.1
LPHW Connection Sizes
mm
22
22
22
(1) Entering air 24°C/45% RH 35°C Ambient
(2) Entering air 24°C/45% RH water 7/12°C
(3) Machine weight includes a refrigerant charge / operating weight includes calculated water volume
(4) For refrigerant charges, refer to Unit Refrigerant Charge (kg/Circuit)
(5) Based on air temperature of 15.5°C
leaving the evaporator coil
(6) Based upon low pressure hot water 82°C inlet/71°C outlet. Air on 20°C
(7) Fan gain based on 25Pa ESP @ nominal air volume. Fan gain figure will change as airflow and ESP change.
X2
C0
