Airedale SmartCool 11-233kW - Manual (Page 207)

Precision Air Conditioning SmartCool
TM
– D
Precision Air Conditioning
207
Installation, Maintenance and Commissioning Manual :6877419 02/2013
Vertical
Sound
Overall
dB(A)
Frequency (Hz) dB
Measurement 63 125 250 500 1000 2000 4000 8000
CR12
Power 75 69 86 75 68 69 65 61 51
Pressure @ 10m 47 41 58 47 40 41 37 33 23
CR16
Power 75 69 86 75 68 69 65 61 51
Pressure @ 10m 47 41 58 47 40 41 37 33 23
CR22/DR10
Power 79 80 90 73 74 74 70 64 63
Pressure @ 10m 51 52 62 45 46 46 42 36 35
Power 83 80 83 82 79 79 73 68 60
CR26/DR12 Pressure @ 10m 55 52 55 54 51 51 45 40 32
CR30/DR15
Power 79 80 90 73 74 74 70 64 63
Pressure @ 10m 51 52 62 45 46 46 42 36 35
Power 83 80 83 82 79 79 73 68 60
CR35/DR20 Pressure @ 10m 55 52 55 54 51 51 45 40 32
CR50/DR25
Power 82 83 93 76 77 77 73 67 66
Pressure @ 10m 54 55 65 48 49 49 45 39 38
Power 86 83 86 85 82 82 76 71 63
CR60/DR30 Pressure @ 10m 58 55 58 57 54 54 48 43 35
CR65/DR35
Power 82 83 93 76 77 77 73 67 66
Pressure @ 10m 54 55 65 48 49 49 45 39 38
Power 86 83 86 85 82 82 76 71 63
CR75/DR45 Pressure @ 10m 58 55 58 57 54 54 48 43 35
CR80/DR40
Power 84 78 93 79 78 80 75 69 68
Pressure @ 10m 56 50 65 51 50 52 47 41 40
Power 88 85 88 87 84 84 78 73 65
CR95/DR50 Pressure @ 10m 60 57 60 59 56 56 50 45 37
CR105/DR55
Power 84 78 93 79 78 80 75 69 68
Pressure @ 10m 56 50 65 51 50 52 47 41 40
Power 88 85 88 87 84 84 78 73 65
CR130/DR70 Pressure @ 10m 60 57 60 59 56 56 50 45 37
Power 85 78 94 81 78 81 77 71 70
CR140/DR75 Pressure @ 10m 57 50 66 53 50 53 49 43 42
Power 89 86 89 88 85 85 79 74 66
CR165/DR95 Pressure @ 10m 61 58 61 60 57 57 51 46 38
O
U
T
D
OOR
