Airedale SmartCool 11-233kW - Manual (Page 211)

Precision Air Conditioning SmartCool
TM
– D
Precision Air Conditioning
211
Installation, Maintenance and Commissioning Manual :6877419 02/2013
Mechanical Data- Condensers and Dry Coolers
CR130 CR140 CR165
DR75 DR70 DR95
Total Heat of Rejection CR (1) kW 149.7 150.1 195.7
Total Heat of Rejection DR (2) kW 72 73.7 97.4
Dimensions - Horizontal (3)
H x W x L mm 1167 x 1000 x 3565 1167 x 1000 x 4641 1167 x 1000 x 4641
Dimensions - Vertical (3)
H x W x L mm 1155 x 1167 x 3565 1090 x 1167 x 4641 1155 x 1167 x 4641
Weight
Machine kg 310 349 415
Construction
Material/Colour Galvanised Sheet Steel, Epoxy Baked Powder Paint - Light Grey (RAL 7035)
Condenser Air Cooled - Rifled Copper Tube/Turbulated Aluminium Fins
Dry Cooler Air Cooled - Copper Tube/Turbulated Aluminium Fins
Total Face Area m² 3.63 4.8 4.8
Nominal Airflow m³/s 9.3 8.7 12.4
Discharge -H Horizontal or -V Vertical (Please Specify at Order)
Fan & Motor Axial
Quantity 3 4 4
Diameter mm 710 630 710
Maximum Speed rpm 930 895 930
Refrigeration - CR Single Circuit
Refrigerant Type R410A
Holding Charge Inert Gas
Coil Volume l 36.6 TBC TBC
Refrigerant Charge (4) kg 16.7 TBC TBC
Dry Cooler
Internal Water Volume L 43.2 55.9 55.9
Water flowrate l/s 3.4 3.5 4.6
Pressure Drop kPa 53 62 94
Connections
Liquid Line - Sweat in 7/8 7/8 7/8
Discharge Line - Sweat in 1 3/8 1 3/8 1 3/8
OPTIONAL EXTRAS
Short Case Axial Fan Designed to 75 Pa ESP
Dimensions – Horizontal
H x W x L mm 1140 x 1000 x 3565 1167 x 1000 x 4641 1167 x 1000 x 4641
Dimensions – Vertical
H x W x L mm 1140 x 1167 x 3565 1130 x 1167 x 4641 1140 x 1167 x 4641
Weight
Machine kg 345 394 404
EC Fan
Dimensions – Horizontal
H x W x L mm 1167 x 1000 x 3565 1167 x 1000 x 4641 1167 x 1000 x 4641
Dimensions – Vertical
H x W x L mm 1170 x 1167 x 3565 1127 x 1167 x 4641 1170 x 1167 x 4641
Weight
Machine kg 301 375 462
(1) Nominal data based on 35°C ambient and a 50°C mean condensing temperature and using standard fan.
(2) Nominal data based on 35°C ambient and a 45/40°C Water entering/leaving.
(2) Overall dimensions for clearance; refer to
Dimensional & Installation Data , for detail.
(3) For guidance only.
