Martel Electronics LC-110/H User Manual
Page 36
34
Tag Name ♥
Configuration Log
Data Log
The tag name is truncated to fit on one line if necessary. The ♥
symbol in the upper right corner flashes to indicate a working HART
connection.
Rotate the knob to move the reverse video highlight to the desired
action. Press the knob to select the highlighted action and proceed
to the corresponding display described in sections 6.10.1 or 6.10.2.
Press MENU/EXIT to return to the Function Select menu in section
6.5.
6.10.1 Configuration Log
Configuration data for up to 20 tags may be stored for later recall.
The configuration data saved is the same as that shown on the
Device Data screen, section 6.6.
The initial display spans more than one screen and shows a list of
the tags contained in storage. Tag names span two lines if they
exceed the length of a single line. If a storage position is not used,
the tag name area displays ‘
selected, data may be saved to it, recalled from it, erased, or sent to
the RS232 port. The data may also be uploaded to a personal
computer via the BetaLOG HART Windows application. We
recommend that you use PN: 1920049 (Lemo to USB Cable) for use
with the BetaLOG HART Software . It incorporates a USB/Serial
adapter using an FTDI chipset. This combination provides consistent
and reliable communications between the LC-110H and PC. The
USB Drivers are included on the BetaLOG HART Software CD.
Configuration Log ♥
8 Tag 1
on two lines
9
10 Tag 3
11 Tag 4
