Martel Electronics LC-110/H User Manual
Page 28
26
Tag Name ♥
Write URV: degrees F
300.5
Press & hold to Write
The tag name is truncated to fit on one line if necessary. The ♥
symbol in the upper right corner flashes to indicate a working HART
connection.
• Press the knob to move the decade cursor.
• Rotate the knob to increment or decrement the value in steps
indicated by the selected decade.
• Press and hold the knob to send the new value to the HART
device, remaining on this display. An error is displayed if the HART
device rejects the value for any reason.
• Press MENU/EXIT to return to the Modify Setup menu in section
6.7. A reminder to change the loop to AUTOMATIC is displayed
first.
6.7.3 Write PV Unit
A warning to change the loop to MANUAL before proceeding is
displayed. Press the knob to proceed. Press MENU/EXIT to return to
the Modify Setup menu in section 6.7.
The available units are displayed with the present unit highlighted in
reverse video. The available units listed correspond to the type of
unit presently selected. For example, if the present unit is PSI only
pressure units are listed, if the present unit is °C only temperature
units are listed.
Tag Name ♥
Select PV Unit:
degree C
degree F
degree R
degree K
Press & hold to Write
