Sample Screen Image
PT12234 ♥
PT12234
PV Unit: inWC 68F
PV: 226.0 inWC
PV mA: 13.016 mA
PV %: 56.35 %
The tag name is truncated to fit on one line if necessary. The ♥
symbol in the upper right corner flashes to indicate a working HART
connection.
Each screen contains up to 6 items of data. An item may span more
than one line if necessary to display the full text. If a data item is not
supported in the HART device, it is marked “n/a”, not available. Data
items that change dynamically in the HART device are updated as
often as possible on the screens.
The lower left corner contains the symbol when additional screens
follow the present one, the symbol when additional screens
precede the present one, and both when additional screens follow
and precede the present one.
Rotate the knob to step between screens. Press MENU/EXIT to
return to the Function Select menu in section 6.5.
6.7 Modify Setup
If the HART write commands are not enabled per section 4.8, none of
these functions are available and an error message is displayed
instead of the following screen.
Tag Name ♥
Write LRV
Write URV
Write PV Unit
Modify Tags,Msg,Descr
The tag name is truncated to fit on one line if necessary. The ♥
symbol in the upper right corner flashes to indicate a working HART
connection.
