− 1 − KEW6310
Contents KEW6310
● Preface
This Quick manual is a simplified version of the full instruction manual which can be found in the supplied
CD-ROM.
This manual is intended only as a handy reference guide and should only
be used after having read the full instruction manual which contains full details on
each function of this instrument and the items contained in the package.
● Safety Warning!
The instruction manual contains warnings and safety procedures which have to
be observed to ensure safe operation of the instrument and maintain it in a safe
condition. Thus, these operating instructions have to be read prior to using the
instrument.
Contents
１．
Instrument Overview …………………………………………………………………………… 2
２． Instrument Layout ……………………………………………………………………………… 5
３． Getting started ………………………………………………………………………………… 7
４． Setting ………………………………………………………………………………… 10
５． Instantaneous (Inst) value Measurement …………………………………………… 15
６． Integration value Measurement ……………………………………………………… 17
７． Demand Measurement ……………………………………………………………… 19
８． WAVE Range ………………………………………………………………………… 23
９． Harmonic Analysis …………………………………………………………………… 25
10． Power Quality ………………………………………………………………………… 27
Swell / Dip / Short interruption (Int) Measurement ……………………………… 27
Transient Measurement …………………………………………………………… 29
Inrush current Measurement ……………………………………………………… 31
Unbalance Ratio …………………………………………………………………… 33
Flicker ……………………………………………………………………………… 35
Capacitance Calculation …………………………………………………………… 37
11． CF Card / Saved data ………………………………………………………………………… 39
12. Wiring check …………………………………………………………………………………… 42
The latest software can be downloaded from our web site.
http://www.kew-ltd.co.jp
