15

3. Programming

The Level-Sonic BM90 has two modes :

a)

RUN (normal operating)

b)

PROG (programming)

In the ‘RUN‘ mode, the instrument is monitoring the tar-

get, displaying values and setting outputs as pro-

grammed by the operator.

In the ‘PROG‘ mode, the operator uses the keypad in

conjunction with the display to adjust the settings and to

test that the unit is programmed correctly.

3.1. Keypad definitions

The keypad consists of 20 keys which are used to con-

trol the operation of the converter.These keys also have

secondary functions indicated above them (See Figure

5) enabling the operator to view the results being

obtained by the instrument during its normal ’RUN’ cycle.

3.2. Display Descriptions

The following display codes are used :

P R O G

R U N

Pr.XX

C O dE

====

FULL

-FUL

P.rES

t.rES

LOSt

tESt

gAIN

H E A d

F L O

HI.tO

LO.tO

deG.C

dISt

An.OP

Precedes program mode

Precedes run mode

Parameter number

Security code request

No value

Numerical overflow of display

i.e. value too large to display

Negative numerical overflow

Check taht Pr.43 is correct

Resetting to factory parameters

Resetting totalizer

Loss of echo

System performing a requested test

Gain value being displayed

Head

Flow

Totaliser high 4 digits 9999 (----)

Totaliser low 4 digits (----) 9999

Temperature C

Distance

Analogue output

Primary Key Functions

Active Secondary Key Functions

During normal ’RUN’ mode it is possible for an operator

to obtain the data defined as secondary function without

interrupting normal operation, by pressing the appropri-

ate key, i.e.

Key 7

Key 8

C E

Key 9

Key 0

.

_

’s’

Test

E N T

D S P

’t’

Relay 3. Hours energised.

Relay 4. Hours energised.

Relay 5. Hours energised.

Relay 1. Number of times energised.

Relay 2. Number of times energised.

Relay 3. Number of times energised.

Relay 4. Number of times energised.

Relay 5. Number of times energised.

Displays gain

Displays mA output.

Displays distance from the transducer face.

Displays temperature.

Keys 1 - 4

Key 5

Key 6

Show high totaliser, low totaliser, head and

flow when in the OCM mode. Head will

always show level.

Relay 1. Hours energised.

Relay 2. Hours energised.

0 - 9

.

-

C E

#

M O D E

TEST

’s’

’t’

D S P

E N T

Numerical Values

Decimal Point

Negative value (also used to slow down

simulation)

Clear Entry (also used to leave test func-

tions Pr.75 to Pr.78.)

Returns display to normal ’RUN’ mode

after viewing secondary functions (also

speeds up simulation Pr.78)

Alternates between ’RUN’ and ’PROG’

mode.

Displays gain in ’RUN’ mode and allows

parameter interrogation and simulation

hold in ’PROG’ mode.

Increase parameter number (also control

of simulation direction).

Decrease parameter number (also control

of simulation direction)

Display parameter number/value alter-

nately.

Enter a new value or initiate a system test

under Pr.75 to Pr.78
