Chapter 8. Dedicated Maps Terminal Menu
61200266L1-1 ATLAS 810 PLUS User Manual 8-7
by-step procedures for creating a sample dedicated map based on the con-
nections and ports given in Table 8-1.
Configuring the Ports for Example 2
Begin by navigating to Terminal Menu/Modules . From this menu, configure
the various ports to match the framing parameters of the T1 line provided
by the telco.
Table 8-1. Connections and Ports
Name ATLAS 810
PLUS
Port DS0s Name ATLAS 810
PLUS
Port DS0s
T1:
Data A Controller T1
Slot 0 Port 1 9-24
RBS Off V.35 - A Quad V.35
Slot 2/Port 1 N/A
T1:
Data B Controller T1
Slot 0/Port 2 9-24
RBS Off V.35 - B Quad V.35
Slot 2/Port 2 N/A
T1:
Data C Quad T1/PRI
Slot 1/Port 1 9-24
RBS Off V.35 - C Quad V.35
Slot 2/Port 3 N/A
T1:
Voice A Controller T1
Slot 0/Port 1 1-8
RBS On T1-D Quad T1/PRI DSX
Slot 1/Port 2 1-8
RBS On
T1:
Voice B Controller T1
Slot 0/Port 2 1-8
RBS On T1-D Quad T1/PRI DSX
Slot 1/Port 2 9-16
RBS On
T1:
Voice C Quad T1/PRI
Slot 1/Port 1 1-8
RBS On T1-D Quad/PRI DSX
Slot 1/Port 2 17-24
RBS On
Instructions for Configuring the Ports
Step Action
1 Select Slt / 0 (system controller T1/PRI port).
2
Set the line framing parameters by selecting Menu /
Configuration / Frame / ESF.
3
Copy this configuration information for use with additional ports.
(Navigate to Prt and press
C .)
4
Navigate to the port index number of the second port (Prt) and
press
P to paste the configuration information. Press Y to confirm
paste.
5 Repeat Step 4 for the first port of the T1/PRI card located in Slot 1.
6
Navigate to the V.35 port Configuration submenu and repeat
Step 2 for the first port, followed by a copy-and-paste to the
second and third ports (see Figure 8-4).
