Chapter 12. ADTRAN Utilities
12-8 ATLAS 810 PLUS User Manual 61200266L1-1
VT-100 UTILITY
Use the VT-100 to configure an ATLAS 810
PLUS
which is directly connected
to a PC. The VT-100 display is almost identical to the Telnet display.
For a detailed description of how to work with the Telnet program, refer to
Navigating the Terminal Menu on page 5-1, and for a detailed description of
the VT-100 interface, see VT-100 Utility on page 12-8. If you need help setting
up the ATLAS 810
PLUS
for a VT-100 session, refer to Using VT-100 Terminal
Emulation on page 3-1.
VT-100 menus include Session , Edit , Port , Options , Capture , and Help
(see the menu tree in Figure 12-4).
Figure 12-4. VT-100 Menu Tree
>
SESSION
MENU
Opens VT-100 terminal emulation session.
» Connect Opens a specified serial port for a VT-100 session.
» Disconnect Closes a specified serial port at the end of a VT-100 session.
» File Transfer Uploads and downloads files to and from an ATLAS.
Connect
Session Disconnect
File Transfer XMODEM CRC
Exit ASCII Cfg Files Send Cfg File
Edit Copy
Paste
Port Settings
Refresh Screen Transmit Wakeup
Connect Transmit Refresh
VT-100 Options Colors
Local Echo BackGround
Auto Repeat Bold
Text
File Start Cfg Capture
Capture Buffer Size Stop Cfg Capture
Save Buffer As
Screen Capture
Help Contents
About
