Chapter 4. Using the Front Panel
4-2 ATLAS 810 PLUS User Manual 61200266L1-1
CRAFT PORT
Use the CRAFT port to configure the system via an EIA-232 connection. The
CRAFT port provides the same functions and operations as the Control In
port located on the rear panel of the ATLAS 810
PLUS
. Table 4-1 gives the
CRAFT port pinout (see also CRAFT Port on page 4-3 in Table 4-2).
THE FRONT PANEL LEDS
With the ATLAS 810
PLUS
powered-up, the front panel LED display provides
visual information about the status of the ATLAS 810
PLUS
and any option
modules that may be installed. Table 4-2 on page 4-3 provides a brief de-
scription of the front panel features, and Table 4-3 on page 4-4 provides de-
tailed information about the LEDs.
Table 4-1. CRAFT Port Pinout
PIN NAME DESCRIPTION
1 GND Ground - connected to unit chassis
2 RTS Request to send - flow control
3 RXDATA
Data received by the ATLAS 810
PLUS
4 DTR Data terminal ready
5 TXDATA
Data transmitted by the ATLAS 810
PLUS
6 CD Carrier detect
7 UNUSED —
8 CTS Clear to send - flow control
