Chapter 6. Terminal Menu and System Control
6-22 ATLAS 810 PLUS User Manual 61200266L1-1
»» Clear Self-test Log Write security: 3; Read security: 5
Clears the self-test log.
» Ping Write security: 5; Read security: 5
Allows you to send pings (ICMP requests) to devices accessible via the net-
work.
»» IP Address Write security: 5; Read security: 5
Specifies the IP address to ping.
»» Count Write security: 5; Read security: 5
Specifies the number of pings to send. The default number of tries is 4, and
the maximum value is 99.
»» Size Write security: 5; Read security: 5
Specifies the size in bytes of the data portion of the ping request. The
default value is 64 bytes, and the maximum size is 1024 bytes.
»» Timeout Write security: 5; Read security: 5
Specifies the time in milliseconds to wait for the ping reply before timing
out. The default timeout is three seconds, and the maximum timeout value
is ten seconds.
»» Round trip min Read security: 5
Displays the minimum round trip time of the ping request/reply of the cur-
rent set of pings.
»» Round trip avg Read security: 5
Displays the average round trip time of the ping request/reply of the cur-
rent set of pings.
»» Round trip max Read security: 5
Displays the maximum round trip time of the ping request/reply of the cur-
rent set of pings.
»» Tx Stats Read security: 5
Displays the number of ping requests transmitted (
n txed ), the number of
ping replies received ( n rxed ) and the number of ping requests that were
lost ( n lost ).
»» Reset Stats Write security: 5; Read security: 5
Resets all ping statistics to zero. If the ping client is active, this menu will
stop it.
Only one ping session can be active at a time.
