ABC 040104

3-17

3.6.3.3

XON XOFF METHOD

The XON XOFF method allows the ABC to control when the command originator is allowed to
send data. The command originator can only send data after the XON (transmission on) charac-
ter (011

H

) has been received; the command originator stops sending data after receiving the

XOFF (transmission off) character (013

H

), and waits until the XON character is received before

sending additional data.

Control characters, either CR or LF, are returned as XOFF CR if echo mode is on, and as XOFF
if echo mode is off. XOFF stops data from the command originator and the ABC returns the nor-
mal sequence of CR LF (if echo mode is enabled).

3.6.4

ISOLATING RS 232 COMMUNICATION PROBLEMS

A Loop Back test can be run from the front panel to aid in isolating RS 232 communication prob-
lems. The unit is designed to pass the test only with the Loop Back test connector (part of Kit
219-0436, see Table 1-4) installed.

1. With the power supply in local mode, command entry status , press MENU key until LCD

reads

LOOP BACK TEST UNTESTED 1=RUN

.

2. Press the 1 key to run the test with the Loop Back Test connector NOT installed and very the

LCD reads

FAILED

. If the LCD reads

PASSED

, the power supply is defective and requires

repair.

3. Install the loop back test connector into RS 232 port and press the 1 key to rerun the test. If

the LCD reads

PASSED

, the power supply is operating properly. If the LCD reads

FAILED

,

the unit requires repair.

4. To test the integrity of the cable assembly connecting the power supply RS 232 port to the

computer, remove the Loop Back test connector from the power supply RS 232 port and
connect the cable in its place. With the DB9 adapter installed on the opposite end of the
cable, connect a short jumper wire between pins 2 and 3 of the adapter connector and
repeat the test of (3) above. If the LCD display reads

FAILED

, the cord is either the improper

type (not null modem) or is defective. If the LCD display reads

PASSED

, the cable is correct;

remove the jumper and reconnect the cable to the computer.

If each of the above steps is completed successfully, the problem lies in the computer hard-
ware and/or software. Refer to the Product Support area of the Kepco website for additional
information regarding RS 232 communications problems: www.kepcopower.com/support.

3.7

SCPI PROGRAMMING

SCPI (Standard Commands for Programmable Instruments) is a programming language con-
forming to the protocols and standards established by IEEE 488.2 (reference document
ANSI/IEEE Std 488.2, IEEE Standard Codes, Formats, Protocols, and Common Commands). SCPI
commands are sent to the ABC Power Supply as ASCII output strings within the selected pro-
gramming language (PASCAL, BASIC, etc.) in accordance with the manufacturer’s require-
ments for the particular GPIB controller card used.

Different programming languages (e.g., BASIC, C, PASCAL, etc.) have different ways of repre-
senting data that is to be put on the RS 232 or IEEE 488 (GPIB) bus. It is up to the programmer
to determine how to output the character sequence required for the programming language
used. Address information (GPIB address) must be included before the command sequence.
(See PAR.3.5.2 to establish the ABC Power Supply GPIB address.)
