1-8
ABCOPR040104
1.6.5 USER-DEFINED VOLTAGE/CURRENT LIMITS
The ABC output can be programmed not to exceed user-defined values. For example, the ABC
10-10DM, which has a maximum capacity of 10V, 10A, can be limited to 5.5V, 1A for working
with circuitry that might be damaged by higher levels. Once the limits are set, the power supply
becomes, in effect a 5.5V,1A supply and values exceeding the limit values will not be accepted.
Refer to PAR. 3.3.11.
1.6.6 EXTERNAL TRIGGER/REMOTE ON-OFF PORT
The external trigger/Remote on off port provides two functions: One pin allows the unit to be
triggered to return to previously stored settings using SCPI commands (see PAR. B.101).
Another pin allows the output to be set to zero Volts, zero Amperes from a remote location using
a single dedicated line (see PAR. 3.2).
1.7 EQUIPMENT SUPPLIED
The unit is shipped with a standard Power Cord, IEC to 115 VAC (USA),
1.8 ACCESSORIES
Accessories for the ABC Power Supply are listed in Table 1-4.
TABLE 1-4. ACCESSORIES
ITEM FUNCTION PART NUMBER
Rack Adapter Accepts a single ABC power supply for installation in a 19-inch wide
rack (see Figure 1-2).
RA 71
Rack Adapter Accepts a two ABC power supplies for side by sided installation in a 19-
inch wide rack (see Figure 1-3).
RA 72
IEEE 488 Cable, (1 meter long) Connects ABC power supply to GPIB bus SNC 488-1
IEEE 488 Cable, (2 meter long) Connects ABC power supply to GPIB bus SNC 488-2
IEEE 488 Cable, (4 meter long) Connects ABC power supply to GPIB bus SNC 488-4
Fuse Circuit Protection (Replacement of Fuse A2FS1 is authorized by ser-
vice personnel only.) IEC TYPE T,
3.15A, 250V a-c
External Trigger mating con-
nector (9mm 3-pin earphone
jack) Allows access to remote trigger and remote output on/off functions 142-0486
(Power Dynamics
MDP-023)
RS 232 Cable Kit Contains RJ 45 Patch cord, two RS 232 adapters, one with male pins to
connect to DTE equipment and one with female pins to connect to a PC
(personal computer,.and an RS 232 Loop Back test Connected to test
RS 232 communication and aid in isolating RS 232 communication
problems.
KIT 219-0436
