KANOMAX 3800 Handheld Condensation Particle Counter - Manual (Page 38)

31
5. Main Specifications
Measuring Particle Size 0.015 to 1µm
Concentration Range 0 to 100,000 particles/cm 3
Counting Efficiency 50nm: 100±20% (15nm: 50% and above)
Zero Count 1 particle/cm 3 or less
Flow Rate
Aerosol Flow: 100cc/min.
Total Flow: 700cc/min.
Type Isopropyl Alcohol (Purity: 99.5%)
Alcohol
Supply
Hours per Fill Approx. 5 hours (at 21 degrees C)
Absolute Pressure at Inlet 150 to 1150 hPa
Measurement Modes Normal / Repeat / Program / Counter
Communication USB
Printer Communication
Requirements
No Parity, Bit length: 8 bits, Stop bit: 1
Memory (Maximum) 10,000 data records
Type
Six (6) AA Alkaline Batteries / Nickel Metal Hydride Batteries or
AC Adapter (Input 100-240V)
Power
Supply
Operating Hours
Alkaline batteries: Approx. 5 hours
Nickel Metal Hydride Batteries: Approx. 8 hours
Ambient Temperature Range 15 to 30 degrees C
Dimensions 120(W) × 280(H) × 130(D) mm
Weight Approx. 1.5kg (without batteries)
