10. Enter the TROLL Link password, if applicable.
11. Ensure the Mode is set to Modbus-ASCII.
12. Click the check mark.
13. Click the connect button in the lower-right corner.
14. Click the Logging tab, click the desired log and click Download
15. Click the disconnect button in the lower-left corner.
Stopping SMS Messages
The directions below describe turning off SMS messages using a direct serial
connection.
1. Follow the steps in the section Connecting the TROLL Link to the PC.
2. On the Schedule tab, click Clear All.
3. Click the Load Configuration button.
The modem no longer transmits messages, but still draws power
from the battery.
The directions below describe turning off SMS messages using a remote IP connection.
1. Open the TROLL Link Setup Software.
2. Click the Connect button.
3. Click the radio button next to IP Connection.
4. Enter the TROLL Link Telemetry System IP Address and IP Port number. These
numbers are listed in the Remote Site Connections window or on the Summary tab.
5. Enter the number of retries (user-defined).
6. Enter the TROLL Link password (if applicable).
7. Click the check mark.
8. On the Schedule tab, click Clear All.
9. Click the Load Configuration button.
The modem no longer transmits messages, but still draws power
from the battery.
