2. After wiring the stripped-and-tinned Rugged Cable, connect either a cable connect
USB or RS232 TROLL Com communication cable to the twist-lock connector on the
cable.
3. Attach the TROLL Com to a PC running Win-Situ 5 or a RuggedReader running
Win-Situ Mobile.
4. Click the Connect button to initiate communications between the controller and the
PC software.
Connecting the Con TROLL PRO to Win-Situ 5 Software
1. Install Win-Situ 5 from the In-Situ software CD. Open Win-Situ 5.
2. In the Win-Situ 5 menu bar, select Preferences, then Comm Settings.
3. Make sure that the communication settings are set as follows.
