Using the Commands

41

U

SING THE

C

OMMANDS

The command function in Freewave allows the oscilloscope to be
controlled remotely without using a separate terminal application.
Commands are categorized and labeled along with their
descriptions. Data format and command order can be semi-
automatically configured. Command results are shown in the screen
and can be saved to a CSV file. Here are the available operations:

Preparing a command list

Configuring and running commands

Saving a command list and its result

Preparing a Command List

1. Activate Freewave and connect the oscilloscope to the PC. For

details, see page19.

2. Select the leftmost Command tab.

3. Click on the “DSO Command” node on the left

side. A detailed command list appears.

Command list

The Command description area contains three
types of information:

Command: shows the command name in short
mode

Description: describes what the command does

Data: shows the command’s data format

For more details, see the GDS-1000-U, GDS-1000A-
U and GDS-3000 Programming Manual.
