Freewave Manual

32

Taking a Video Clip of the Display
Contents(GDS-1000-U and GDS-1000A-U
only)

1. Make sure the oscilloscope’s display contents appear in the

Freewave screen, updated in real-time (Play mode).

2. Select the recording area by selecting either “Freewave Screen” or

“Oscilloscope Display” in the Video Recording Area panel.

3. Click on the Record button. Freewave

automatically starts recording the display contents.

4. To stop the recording, click on the Stop button

which will open a file save dialog box. Enter the file
name, select the directory, and save the video in the
*.wmv format.
