PST & PSS & PSH SERIES PROGRAMMABLE POWER SUPPLY
PROGRAMMER MANUAL
⎯ 29 ⎯
Examples:
:OUTPut:COUPle:TRACking
2 set the output of the channel 1 and
channel 2 to series-tracking mode.
If the output is in the parallel-tracking mode, the command of
OUTPut:COUPle:TRACking?
will return the value of 1.
OUTPut:PROTection:CLEar (no query form)
Function:
Clear all the protective messages (OTP, OVP, OCP) from the panel of the
device.
Syntax:
OUTPot:PROTection:CLEar
When the panel displays the protective message, no further setting can be
accepted by the device. Uses this command to clear the displayed
messages in order to execute further setting.
Examples:
OUTPot:PROTection:CLEar
OUTPut:STATe
Function:
Set the output state on or off.
Syntax:
OUTPut:STATe
OUTPut:STATe?
can be 0(OFF) or 1(ON).
Returns:
0|1
PST & PSS & PSH SERIES PROGRAMMABLE POWER SUPPLY
PROGRAMMER MANUAL
⎯ 30 ⎯
Examples:
OUTPut:STATe 1 enables the power supply output.
If the power supply output is disabled, OUTPut:STATe? will return 0.
STATus:OPERation:CONDition? (query only)
Function:
Return the contents of the OPERation register. The programmable power
supplies, however, do not use the OPERation register to report any
conditions.
Syntax:
STATus:OPERation:CONDition?
Returns:
Examples:
STATus:OPERation:CONDition? returns 0.
STATus:OPERation:ENABle
Function:
Set or query the enable mask that allows the masked conditions in the
event register to be reported in the summary bit. If a bit is 1 (true) in the
enable register and its associated event bit changes to 1 (true), the
associated summary bit will change to 1 (true). Even though this is a 16-
bit register, only 15 bits (bit 0 through bit 14) are used. Bit 15 always
reads 0.
Syntax
STATus:OPERation:ENABle
STATus:OPERation:ENABle?
is an integer from 0 to 32767.
