PST & PSS & PSH SERIES PROGRAMMABLE POWER SUPPLY
PROGRAMMER MANUAL
⎯ 21 ⎯
Examples:
*IDN? Returns WK.TMPRO,PST-3202,A000000,FW1.00
*OPC
Function:
The command form (*OPC) sets the operation complete bit (bit 0) in the
Standard Event Status Register (SESR) when all pending operations are
finished.
The query form (*OPC?) tells the programmable power supply to place
an ASCII 1 in the Output Queue when the power supply completes all
pending operations.
Syntax:
*OPC
*OPC?
Returns:
1
*RCL
Function:
Recall the setting data from the memory saved previously. (The PSS and
PSH series do not have this function)
Syntax:
*RCL
is in the range from 0 through 99.
Examples:
*RCL 12 recalls the setting data stored in memory location 12.
PST & PSS & PSH SERIES PROGRAMMABLE POWER SUPPLY
PROGRAMMER MANUAL
⎯ 22 ⎯
*RST (no query form)
Function:
Set all control settings of power supply to their default values but does
not purge stored setting. The equivalent panel control will be set as
below:
Front Panel Control Default Setting
OUTPUT OFF
CURRENT SET 0
VOLTS SET 0
OCP SET OFF
DELAY 1 sec
AUTO SET OFF
RECALL (memory location) 00
OVP SET MAXimum (Please refer to
the user manual for the OVP
setting)
OUTPUT MODE (INDEP/
SERIES/PARALLEL)
INDEP
STEP SET MINIMUM (Please refer to
the user manual.)
RECALL RANGE
START 00 END 05
CYCLE 1
Syntax:
*RST
