GETTING STARTED
5
Activating Optional Software
Background The GDS-3000 has Power Analysis software (page
13), Serial bus decoding software as well as other
GW Instek software packages as optional extras.
An activation key is required to activate the
software. An activation key is required for each
optional software package.
For the latest files and information regarding the
optional software packages, see the GW Instek
website: www.gwinstek.com
Activation key
filenames Power analysis
activation keys XX.LIS
Steps 1. Insert a USB stick into the front
panel USB port with the activation
keys located in the root directory.
2. Press the Utility key.
3. Press File Utilities from the bottom
menu.
4. The file system appears.
