MEASUREMENT

29

7. Press Select and use the Variable

knob to choose a harmonic
measurement to view or to
navigate the harmonic list.

Select

1~number of measurement results

Table Example

Graph Example

Save Harmonic Measurements

Background

All harmonic measurements can be saved
internally or to USB. The files are stored as .CSV.

Panel operation

1. Press the Test key.

2. Press Power Analysis from the

bottom menu.
