GDS-3000 Power Analysis User Manual
14
Power Analysis
The Power Analysis software provides automatic measurement for
a number of advanced measurement types such as power quality,
harmonics, ripple and inrush current. The Power analysis software
is an optional software module. To install the optional software
module, please see page 5.
Power Analysis overview
Power Quality Power quality measures the power of a signal from
the voltage and current measurement.
Harmonics The harmonics function shows signal harmonics
up to the 400th harmonic. Harmonic tests can be
user defined and common harmonic standards
such as IEC 61000-3-2 can also be tested for.
Ripple The ripple function automatically calculates the
ripple and noise of the waveform.
Inrush Current The inrush function automatically calculates the
first peak and second peak inrush current.
