GW Instek GDS-3000 Series DS3-PWR Power analysis manual User Manual
Page 18
GDS-3000 Power Analysis User Manual
18
5. Press Define Inputs from the lower
menu.
6. Choose the Voltage input
(differential voltage source) from
the side menu.
Range
CH1~4
7. Choose the Current input (current
probe source) from the side menu.
Range
CH1~4
8. Press Meas. Display.
9. Choose what type of automatic measurements
should be displayed from the side menu.
Range
Turn Off All Meas.
Normal
Inrush
Ballast
Turn On All Meas.
