GOS-6112 OSCILLOSCOPE
USER MANUAL
 v 
EC Declaration of Conformity
We
GOOD WILL INSTRUMENT CO., LTD.
No. 7-1, Jhongsing Rd., Tucheng City, Taipei County 236, Taiwan
GOOD WILL INSTRUMENT (SUZHOU) CO., LTD.
No. 69 Lushan Road, Suzhou New District Jiangsu, China.
declares that the below mentioned product
GOS-6112
is herewith confirmed to comply with the requirements set out in the Council
Directive on the Approximation of the Law of Member States relating to
Electromagnetic Compatibility (89/336/EEC, 92/31/EEC, 93/68/EEC) and Low
Voltage Equipment Directive (73/23/EEC).
For the evaluation regarding the Electromagnetic Compatibility and Low Voltage
Equipment Directive, the following standards were applied:
EN 61326-1: Electrical equipment for measurement, control and laboratory
use –– EMC requirements (1997+A1: 1998)
Conducted and Radiated Emissions
EN 55011 class B: 1991
EN 55022 class B: 1994 Electrostatic Discharge
EN 61000-4-2: 1994
Current Harmonic
EN 61000-3-2: 1995 Radiated Immunity
ENV 50140: 1993
Voltage Fluctuation
EN 61000-3-3: 1995 Electrical Fast Transients
EN 61000-4-4: 1995
Surge Immunity
EN 61000-4-5: 1995
Conducted Susceptibility
EN 61000-4-6: 1996
Power Frequency Magnetic field
EN 61000-4-8: 1993
Voltage Dips/ Interrupts
EN 61000-4-11: 1994
Low Voltage Equipment Directive 73/23/EEC & amended by 93/68/EEC
Safety Requirements
EN 61010-1: 1990+A1: 1992+A2: 1995
IEC 61010-1: 1990+A1: 1992+A2: 1995
GOS-6112 OSCILLOSCOPE
USER MANUAL
 1 
1.PRODUCT INTRODUCTION
1-1. Description
The GOS-6112 is a 100MHz, two-channel, dual-sweep, portable oscilloscope
for general purpose use. A microprocessor-based operating system controls
most of the functions of the instrument, including cursor readout and
digitized panel setting. On-screen alphanumeric readout and cursor function
for voltage, time, frequency and phase measurement provide extraordinary
operational convenience.
The vertical deflection system has two input channels. Each channel has 11
basic deflection factors from 2mV to 5V per division. The horizontal
deflection system provides single, dual or delayed sweeps from 0.5s to 50ns
per division (delayed sweep, 50ms to 50ns per division). The trigger system
provides stable triggering over the full bandwidth of the vertical deflection
system.
