GOS-6103C OSCILLOSCOPE
USER MANUAL

5

Horizontal Modes MAIN(A), ALT, DELAY(B)
A (main) Sweep Time
50ns~0.5s/DIV, continuously variable
(UNCAL)
B (delay) Sweep Time 50ns~50ms/DIV
Accuracy ± 3% (± 5% at × 10 MAG)
Sweep Magnification × 10 (maximum sweep time 5ns/DIV)
Hold Off time Variable
Delay Time 1us~5s
Delay Jitter 1/20000 or less
HORIZONTAL
DEFLECTION
SYSTEM
Alternate Separation Variable
Sensitivity Accuracy
X-axis, Y-axis selectable
X-axis: CH1, CH2
2mV~5V/DIV ± 3%
EXT 0.1V/DIV ± 5%
Y-axis: CH1,CH2 2mV~5V/DIV ± 3%
X-axis Bandwidth DC~500kHz (-3dB)
X-Y
OPERATION
Phase Error 3°or less at DC~50kHz
Cursor Measurement Function ΔV,ΔV%,ΔVdB,ΔT,1/ΔT,ΔT%,ΔΘ.
Cursor Resolution 1/100 DIV
Effective Cursor Range Vertical: ± 3 DIV; horizontal: ± 4 DIV
CURSOR
READOUT
FUNCTION
Panel setting Vertical: V/DIV (CH1,CH2),UNCAL, ADD,
INV, P10, AC/DC/GND.
Horizontal: S/DIV (MTB, DTB), UNCAL
x 10MAG, Delay time, Hold-off.
Trigger: Source, Coupling, Slope, Level ,
TV-V/TV-H.
Others: X-Y, LOCK, SAVE/RECALL
MEM 0-9.
Parameter Function
FREQ, PERIOD,±WIDTH, ±DUTY,
(+ or – polarity selected by trigger slop.)
Display Digits Max. 6 digits, decimal.
Frequency Range 50Hz~100MHz.
Accuracy 1kHz~100MHz: ±0.01%
50Hz~1kHz : ±0.05%
AUTO
MEASUREMENT
FUNCTION
Measuring Sensitivity >2div(measuring source selected from CH1
and CH2 as synchronous signal source.)
Type 6-inch rectangular type with internal graticule
0%, 10%, 90% and 100% markers.
8 x 10 DIV (1 DIV = 1 cm)
Phosphor P31
Accelerating Potential
16kV approx.
CRT
Illumination Continuous adjustable
GOS-6103C OSCILLOSCOPE
USER MANUAL

6

External intensity modulation
Coupling DC
Voltage
5V or more
Maximum Input Voltage 30V (DC+AC peak) at 1kHz or less
Z-AXIS
INPUT
Bandwidth DC~5MHz
Voltage
25mV/DIV approx. in 50Ω termination
Frequency Response DC~10MHz
TRIGGER
SIGNAL
OUTPUT
Output Impedance 50Ω approx.
Waveform 1kHz ± 5%, square wave
Voltage 2Vpp ± 2%
CALIBRATOR
OUTPUT
Impedance 2kΩ approx.
TIME/DIV Auto Range Provided
Panel Setting Save & Recall 10 sets
SPECIAL
FUNCTION
Panel Setups Lock Provided
Voltage AC 100V, 120V, 230V ± 10% selectable
Frequency 50Hz or 60Hz
LINE POWER
REQUIREMENT
Power Consumption Approx. 90VA, 70W(max.)
OPERATING
ENVIRONMENT
Indoor use
Altitude up to 2000 m
Ambient temperature :
To satisfy specifications : 10
° to 35℃ ( 50 ° to 95 ° F )
Maximum operating ranges: 0 ° to 40℃( 32 ° to 104 ° F )
Relative humidity:85% RH(max.) non condensing
Installation Category II
Pollution degree 2
STORAGE
TEMPERATURE
& HUMIDITY
-10 ° to 70℃, 70%RH(maximum)
Dimensions 310 W × 150 H × 455 D (mm) MECHANICAL
SPECIFICATION Weight
Approx. 9kg (19.8 lbs)
ACCESSORIES
Power cord….............……….. 1
Instruction manual…………… 1
Probe (Ч1/Ч10)…………..… 2
