GOS-6103C OSCILLOSCOPE

USER MANUAL

25

(30)DELAY-HO—Control knob with a double function and associated

LED.

The control knob has two different functions depending on the time

base mode.

HO (Hold-off time)

In MAIN time base mode, the control knob applies to the hold off

time setting, the HO-LED associated with the knob is dark, the hold

off time is set to minimum.

Switch on the LED by turning the control knob clockwise and extend

the hold off time until the maximum is reached. An approximate hold

off time value will be displayed in the readout (“HO: %”).

The hold off time is automatically set to minimum (LED is dark), if

the MAIN time base setting is changed. The hold off time setting is

stored and deactivated if ALT (MAIN and DELAY) or DELAY time

base mode is selected.

DELAY TIME

In ALT (MAIN and DELAY) and DELAY time mode, the knob

controls the delay time setting.

Under the ALT time base mode, the delay time is visible on the main

trace, beginning at the trace start and ending at the start of the

window sector. An approximate delay time value will be displayed in

the readout (“DLY=”).

If only select DELAY time base, the delay time can also be varied,

but there would be no window sector as the main trace is not visible.

GOS-6103C OSCILLOSCOPE

USER MANUAL

26

(31)TV-V/TV-H—Pushbutton for video sync signal selection.

TV-V

Start the main trace at the beginning of a video signal field. SLOPE

polarity must match the composite sync polarity (i.e, “ ” for

negative sync) to obtain TV field triggering on the vertical sync

pulse.

TV-H

Start the main trace at the beginning of a video signal line. SLOPE

polarity must match the composite sync polarity to obtain TV line

triggering on the horizontal sync pulse.

The current setting is displayed in the readout under item “source,

video polarity, TV-H”.

(32)SLOPE ( )—Pushbutton for the triggering slope or video

polarity selection.

If in the AUTO or NML trigger mode, briefly pressing the pushbutton

to select the slope of the signal which is used for triggering the time

base generator. Each time when the pushbutton is briefly pressed, the

slope direction will switch from falling edge to rising edge, and vice

versa.

The current setting is displayed in the readout under item “source,

SLOPE, coupling”.

If in the TV trigger mode, briefly pressing the pushbutton to select the

video polarity, which will be displayed in the readout with a “ ”

symbol of positive video signal and a “ ” symbol of negative

video signal.
