Configuration Appendix B: MS-9200
LDM-32F PN 50055:C 03/20/01
45
Alarm Only Annunciation of Points
The tables below illustrate the configuration of the LDM Series modules to
annunciate the alarm state of all 99 points (detectors or modules) with the first
eight points of address ‘01’ dedicated to the MS-9200 system functions (see
Figure 29 on page 42).
Detectors
Set address ‘01’ and ‘02’ for detectors.
Table 15 Alarm Only Setup - Detectors
Modules
Set address ‘03’ and ‘04’ for modules.
Table 16 Alarm Only Setup - Modules
LDM Module
Address ‘01’
LDM Output Connectors
J5 J6 J7 J8
LDM-32F Sys Funct 1 to 8 9 to 16 17 to 24
LDM-E32F 25 to 32 33 to 40 41 to 48 49 to 56
LDM Module
Address ‘02’
LDM Output Connectors
J5 J6 J7 J8
LDM-32F 57 to 64 65 to 72 73 to 80 81 to 88
LDM-E32F 89 to 96 97 to 99 Not Used Not Used
LDM Module
Address ‘03’
LDM Output Connectors
J5 J6 J7 J8
LDM-32F 1 to 8 9 to 16 17 to 24 25 to 32
LDM-E32F 33 to 40 41 to 48 49 to 56 57 to 64
LDM Module
Address ‘04’
LDM Output Connectors
J5 J6 J7 J8
LDM-32F 65 to 72 73 to 80 81 to 88 89 to 96
LDM-E32F 97 to 99 Not Used Not Used Not Used
