Model MCX-32
Model MCX-32 Instruction Manual Rev. 2.3 Page 47 of 49
Bit 7 Not Used
Bit 8 Not Used
Bit 9 Not Used
Bit 10 Not Used
Bit 11 Not Used
Bit 12 Not Used
Bit 13 Not Used
Bit 14 Not Used
Bit 15 Not Used
Bit 16 Not Used
Notes:
1) Registers 40001~40128 are read only registers. Use Modbus™ Function Code 3 only
2) Register 40129 will accept Modbus™ Function 03 or 06 only
3) The decimal point specifies the divisor for reading registers. Example: Assuming the channel is 01 (40001-40002):
40001=150, 40002=01. User should divide the value in register 40001 by 10 (150/10=15.0).
11.3 Spare Parts
Part Number Spare Parts
360-DLP120-024 120Watt 24VDC Din-rail Mounted Power Supply
320-228120-300 3Amp Din-rail mounted Circuit Breaker
320-228861-105 5Amp Din-rail Mounted Circuit Breaker
500-005133-000 MC Series Interface PCA
995-0G306M-100 Graphic LCD Display, Programmed (must be programmed at Detcon)
995-0G3RS0-000 RS-232 / RS-485 option card (installed in Main MCX-32 Display)
976-041400-000 DA-4 I/O Module
975-041402-000 DI-4 I/O Module
975-041400-000 RL-4 Relay Module
975-041401-000 AO-4 4-20mA Output Module
