Model MCX-32
Model MCX-32 Instruction Manual Rev.2.3 Page 46 of 49
Modbus
Register
MCX-32
Channel Description
Modbus
Register
MCX-32
Channel Description
Modbus
Register
MCX-32
Channel Description
40035 Status* 40079 Status* 40123 Status*
40036
19
Reading 40080
41
Reading 40124
63
Reading
40037 Status* 40081 Status* 40125 Status*
40038
20
Reading 40082
42
Reading 40126
64
Reading
40039 Status* 40083 Status* 40127 Status*
40040
21
Reading 40084
43
Reading 40128 ---
Reset
Switch **
40041 Status* 40085 Status*
40042
22
Reading 40086
44
Reading
40043 Status* 40087 Status*
* STATUS REGISTERS
Bit 0
Alarm 1 0 = No Alarm 1 = In alarm 1
Bit 1 Alarm 2 0 = No Alarm 1 = In alarm 2
Bit 2 Alarm 3 0 = No Alarm 1 = In alarm 3
Bit 3 Fault 0 = No Fault 1 = Sensor Fault
Bit 4 Cal 0 = Normal Operation 1 = In Cal
Bit 5 Comm Error 0 = Normal Operation 1 = Communication Error
Bit 6 &
Bit 7
Decimal Point
00 = No Decimal Point(No Divisor) 10 = 2 Decimal Point (Divisor of 100)
01 = 1 Decimal Point ( Divisor of 10)
Bit 8 Not Used
Bit 9 Not Used
Bit 10 Not Used
Bit 11 Not Used
Bit 12 Not Used
Bit 13 Not Used
Bit 14 Not Used
Bit 15 Not Used
Bit 16 Not Used
** RESEST SWITCH (REGISTER 40129)
Bit 0
Request to Alarm Silence, write a value of 1 to bit 0 using Modbus Function 06
Bit 1 Request to Alarm Reset, write a value of 1 to bit 1 using Modbus Function 06
Bit 2 Not Used
Bit 3 Not Used
Bit 4 Not Used
Bit 5 Not Used
Bit 6 Not Used
