SEED HAWK ® 2015 30 SERIES OPERATOR’S MANUAL – DOMESTIC 41
At the “Menu Settings” screen use the Navigation Keys or the Selector
Knob to place the highlight bar on item "MuxBus Sensor Setup."
1. New system installation: Place the highlight bar on “Auto Detect” and
press the
Soft Key labeled “Install”.
5.4.1 MUXBUS Sensor Settings and Installation
2. Plug in the sensors: Sensors
must be connected in the order listed
on the menu. Different sensors have
different types and cannot be learned
to the wrong location but the first
fan sensor plugged in will be assigned
to Fan 1. The first bin level sensor
plugged in will be learned to Bin 1, etc.
The speed, pressure, and flow sensors
all use the same type sensor code so
the first one plugged in will be the
speed sensor, etc.
3. Add a sensor: Individual sensors
can be added to the MuxBus system
at any time. Place the highlight bar on
the sensor you want to add (Fan 1 in
the example) and press install. Then
plug in the sensor. Multiple sensors
can also be added using this method
but you need to position the highlight
bar on each new sensor and press
the
Soft Key labeled “Install” before
plugging in each sensor.
