SEED HAWK ® 2015 30 SERIES OPERATOR’S MANUAL – DOMESTIC 25
4.5 Preparation Before Filling the Seed
Hopper
Normally the front seed hopper is used for seed and the rear hopper for fertil-
izer. It is also possible to use both hoppers for seed. In that case, the position
of a valve must be changed so that the hopper that normally feeds out fertilizer
will now feed out seed to the seed distributor head. Note that this also re-
quires the Loup III monitor to be reprogrammed.
Check Before Fillling:
 That the machine is empty, clean and dry.
 That the level guards are adjusted correctly (refer to Section 4.5.1).
 To select the proper rotor and gear setting, refer to Section 9.0 for the
Seeding Table and then make the settings in accordance with Section 4.10
and Section 4.11.
 That the emptying hatches are closed (refer to Section 5.10).
The heights of the level guards can be adjusted. The sensors can be moved to
different cutouts in their brackets.
4.5.1 Setting the Level Guards
The six upper positions
are used for corn seed
Bin Level Sensor
The lower position is used for
oilseed and other small size seeds
