Chapter 4
________________________________________________________________________
________________________________________________________________________
BE1285-15 1309 Multipoint Sampler LumaSense Technologies A/S
Page 38 of 42
4.2.4 1309 Check Jobs
Table 4.4 The interface jobs which check the 1309’s functions.
Job Header Data Effect on 1309
Status? No data. Reads-out the 1309’s
status-flag.
Reset_System No data. Resets the 1309.
For further information, refer to section 3.6 .
4.2.5 Error Condition and Service Request Jobs
These jobs allow the identification of error conditions in the 1309. For
further information, refer to section 3.7 .
Table 4.5 The interface jobs which investigate error conditions and al-
low generation of service requests.
Job Header Data Effect on 1309
Ser-
vice_Request_Enable
Decimal value of bits
you want to enable.
Selectively enables bits
in the status byte.
Ser-
vice_Request_Enable
?
No data Reads-out from the
1309 the enabled bits
of the status byte.
Reset_Status_Byte No data. Resets all the bits of
the status byte to zero.
Warning? No data. Reads-out the 1309’s
Warning flags.
Error? No data Reads-out the 1309’s
Error flags.
4.2.6 Standardised Jobs
These jobs do not directly affect the operation of the 1309. The De-
fine_Terminator job is detailed in
section 3.2.1 . The Output_Header job
is detailed in section 3.2.2 .
The jobs with syntax of the type “*RST” are standardised IEEE 488.2
jobs. Most of these jobs are identical to normal 1309 jobs in operation;
the function description refers you to the appropriate 1309 job.
