BE1285-15 1309 Multipoint Sampler LumaSense Technologies A/S
Page 20 of 42
The Waste Air Outlet stub, next to the Outlet to Analyzer, (see fig.
1.3 ) stub on the rear panel of the 1309, connects the external pump to
the 1309’s sampler system. If you do not wish the waste air from the
pump to mix with the air in the room where the 1309 is positioned,
connect a length of PTFE tubing (LumaSense no. AF0614) to the waste
air outlet stub on the external pump and direct the tubing to a suitable
exhaust-point: for example, out of a window.
2.5 Connecting Temperature Transducers to the 1309
The 1309 has 6 temperature-sensor inputs mounted on its front panel,
(see
fig. 1.2 ) suitable for direct use with the INNOVA Air Temperature
Transducer MM0034, Surface Temperature Transducer MM0035 or Op-
erative Temperature Transducer MM0060.
