Section 2.4 Acceptor Handshake (AH) Interface Function,
(Clause 7)
AH 1 – complete capability
Section 2.5 Talker (T) Interface Function, (Clause 8)
T 5 – basic talker, serial poll, talk only mode, un-
address if MLA
Section 2.6 Listener (L) Interface Function, (Clause 9)
L 3 – basic listener, listen only mode, unaddress if
MTA
Section 2.7 Service Request (SR) Interface Function, (Clause
10)
SR 1 – complete capability
Section 2.9 Parallel Poll (PP) Interface Function, (Clause 12)
PP 1 – complete capability
Section 2.10 Device Clear Interface Function, (Clause 13)
DC 1 – complete capability
All other functions – no capability
For further details of the above functions refer to the relevant section of
the IEEE or IEC standards.
4.2 Overview of 1309 Interface Jobs
In this section, each 1309 interface job is grouped according to its func-
tion, with a short description of its effect. The correct syntax for each
job is given, with the minimum code for each job-header, in bold up-
per-case characters. The data for input jobs can be in NR1, NR2 or NR3
format, see section 3.2.1 , unless specifically stated otherwise. The data
for output jobs is in NR2 format unless specifically stated otherwise.
