Chapter 3
________________________________________________________________________
________________________________________________________________________
BE1285-15 1309 Multipoint Sampler LumaSense Technologies A/S
Page 28 of 42
Table 3.2. The 1309’s Status Flag. Each bit represents a particular
1309 component; when set, the 1309 is currently using that
component.
Status Flag
Current function when set Bit
no.
Dec.
value
Bit name
1 1 Sampling valve 1 Sampling valve 1 open
2 2 Sampling valve 2 Sampling valve 2 open
3 4 Sampling valve 3 Sampling valve 3 open
4 8 Sampling valve 4 Sampling valve 4 open
5 16 Sampling valve 5 Sampling valve 5 open
6 32 Sampling valve 6 Sampling valve 6 open
7 64 Sampling valve 7 Sampling valve 7 open
8 128 Sampling valve 8 Sampling valve 8 open
9 256 Sampling valve 9 Sampling valve 9 open
10 512 Sampling valve 10 Sampling valve 10 open
11 1024 Sampling valve 11 Sampling valve 11 open
12 2048 Sampling valve 12 Sampling valve 12 open
13 4096 3-way valve 3-way valve set to analyzer
14 8192 Not used Not used
15 16384 Not used Not used
16 32768 Not used Not used
Example:
STATUS? Outputs the Status flag of the 1309
as described above. Refer to Table
3.2 for the decimal values of each
bit. Refer also to the examples giv-
en below.
If the 1309 outputs 4352, using Table 3.2 shows that 4352 = 256 +
4096. Therefore, bits 9 and 13 are set. The mechanical condition of the
1309 is: sampling valve number 9 open, and 3-way valve set to Ana-
lyzer.
3.6.2 Reset System Interface Job
This job restarts the 1309. The 1309 restarts as described in section
3.1 . Resetting the 1309 cancels any task which the 1309 was perform-
ing prior to the reset.
Example:
RESET_SYSTEM Resets the 1309.
