M330 Manual Introduction 9
2 Introduction
2.1 Description
The M330 is a blackbody calibration source utilizing a digital indicating temperature controller
that may be set to any temperature between 300 °C (572 °F) and 1700 °C (3092 °F). A precision
thermocouple is embedded in the blackbody cavity providing high accuracy and repeatability.
The temperature controller uses the industry standard PID algorithms to control the emitter
temperature to within +/-0.5 °C. The blackbody uses a resistive heater that provide long life.
Running at temperatures greater than 1600 °C for long periods will shorten heater life.
2.2 Technical Data
Temperature Range: 300 C to 1700 C or 572 F to 3092 F
Accuracy: ±0.25% of reading ±1 C
Temperature Resolution: 0.1 C
Stability: 0.5 C per 8 hour period
Source Non-Uniformity: Non-Uniformity: ±1 C within center 1/3 of ID.
Cavity: Closed end tube 41 mm ID X 255 mm long with 125 mm heated
length.
Aperture Diameter: 1.00 (25 mm)
Effective Emissivity 1.0 at 1-1.7 µm and 0.65 µm (radiance calibration only)
Method of Control: Digital Self-Tuning PID Controller
Warm-up Time: 45 minutes from ambient to 300 °C.
65 to 80 minutes from 300 to 1600 C
Operating Ambient Temp.: 0 C to 44 C (32 F to 110 F)
Cooling: Fan cooled, air inlet on rear panel
Power Requirements: [ ]208 [ ]220 [ ]230 [ ]240 VAC ±10% 50/60 Hz 3000 VA
Maximum Weight: 175 lbs. (80 kgs)
2.3 Calibration Certificate
The certificate of calibration of your blackbody source has been enclosed as a part of this
manual or under separate cover. This certificate contains valuable information including
traceability number to NIST. Please observe recommended date of next calibration.
