M330 Manual Operation 15
4 Operation
4.1 Starting Up
1. Allow the M330 to warm-up to room temperature for at least two hours after
unpacking and prior to applying power to remove any condensation.
2. Connect the power cable to a VAC service that matches the power requirement
specification noted in the Technical Data section and on the Specification Label
located on the rear of the M330.
3. Turn on the power switch/breaker and allow 20 seconds for the system to self test.
Warning: Do not exceed the maximum temperature setting of 1700 °C or 3092 °F.
Warning: Do not insert impure materials, metal objects or probes etc. into the cavity.
Warning: Do not connect or disconnect while power is on. Do not disconnect power
when blackbody is hot and fans are running. The fans stay on until the blackbody is
under the safe temperature. The fans will cycle as they are under thermostat control.
4.1.1 Front Panel Push Buttons
PAGE Engages access to controller parameters. Do not alter any
configurations.
SCROLL Engages access to menu items underneath the Page menu.
Allows viewing of output power, working setpoint, and
target setpoint.
UP/DWN Used to raise and lower the temperature setpoint.
