M330 Manual Appendix B: Optional Blackbody Spectral Radiance Correction Software 43
Appendix B: Optional Blackbody Spectral
Radiance Correction Software for M330
Blackbody Source
Description
This program that runs on any PC (Windows 2000/XP) with a free RS-232C port communicates
with the M330 blackbody source controller. The use of this program along with the blackbody
provides automatically compensated radiance outputs regardless of the spectral response of the
infrared thermometer that is being calibrated by the blackbody source.
Installation
Insert the CD into the CD-Rom drive and follow the installation instructions. Attach the RS-232C
cable that came with the blackbody to an available RS-232C port on the PC.
Operation
Use the START menu/programs to begin. The program will automatically find the com port and
display the screen shown above.
Exiting
Click on EXIT button to exit. Upon leaving, the spectral correction is removed from the
controller. This program is required to remain running during any time spectral correction is
required.
Current blackbody
temperature updated
one reading/second
Type desired
blackbody setpoint
here.
SENDs new setpoint
to the blackbody.
Select Mikron’s
Spectral band or enter
your own filter’s
HPBW points if you
select “SPECIAL”.
Current spectral
response used.
Laboratory temperature.
(Default is 23C.)
