BoilerSpection IM Manual
BoilerSpection-IM Assembly 13
3 BoilerSpection-IM Assembly
BoilerSpection-IM is an innovative tool helping today’s plant personnel cope with ever increasing
emissions, fuel flexibility, and increased efficiency expectations. BoilerSpection-IM includes state-of
the-art optics, an infrared camera, and easy-to-use accessories designed for use in industrial furnace
environments include wireless video capture and convenient battery operation.
1. Adjustable radiation shield
2. Interchangeable lens
3. Air fittings for lens
cooling/purge
4. Removable handle
5. Top handle
6. Focus knob
7. BNC video output
8. 12VDC power input
