User Manual of Digital Video Recorder
149
10.4 Configuring Quota Mode
Purpose
Each camera can be configured with allocated quota for the storage of recorded files.
Steps
1. Enter the Storage Mode interface.
Menu > HDD > Advanced
2. Set the Mode to Quota, as shown in Figure 10.17.
Note: The device must be rebooted to activate the changes.
Figure 10. 15 Storage Mode Settings Interface
3. Select a camera for which you want to configure quota.
4. Enter the storage capacity in the text fields of Max. Record Capacity (GB), as shown in Figure 10.18.
Figure 10. 16 Configure Record Quota
5. You can copy the quota settings of the current camera to other cameras if required. Click to enter
the Copy Camera menu, as shown below.
