User Manual of Digital Video Recorder
138
9.4.3 Checking Network Status
Purpose:
You can also check the network status and quick set the network parameters in this interface.
Steps:
1. Enter the Network Traffic interface.
Menu > Maintenance > Net Detect
2. Click the Network Detection tab to enter the Network Detection interface.
3. Click Status to get the network status.
Figure 9. 37 Checking Network Status
If the network is normal the following message box pops out.
Figure 9. 38 Network Status Checking Result
If the message box pops out with other information instead of this one, you can click to show
the quick setting interface of the network parameters.
Figure 9. 39 Network Parameters Configuration
