74 Brocade VDX 8770-8 Hardware Reference Manual
53-1002564-04
Power supply removal and replacement
5
FIGURE 24 Removal and replacement of the power supply
Replacing an AC power supply
If you are not replacing the power supply, insert a filler panel into the slot.
For the following procedure, refer to Figure 24 .
To replace a power supply, complete the following steps.
DANGER
High Touch Current. Earth connection essential before connecting supply (Brocade VDX 8770-8).
1. Unpack the new power supply and remove it from the anti-static bag.
2. Inspect the power supply for damage.
3. Ensure that the handle of the replacement power supply is pushed down.
4. Insert the power supply into the slot.
