System size and weight
A
System size and weight
The weight of the Brocade VDX 8770-8 can vary considerably depending on the combination of
modules installed. Use
and
to determine the weight of the Brocade VDX 8770-8
with your combination of modules.
Scalability
Full fabric architecture (Refer to the current Network OS Release Notes for the most
up-to-date information.)
Brocade ISLs and
Brocade Trunking
Interfaces (line card ports) automatically come up as Fabric inter-switch links (Fabric
ISLs) in VCS mode. If ISL formation fails, the interfaces come up as edge ports.
Trunk groups of up to eight ports are supported on the 48x10 GbE line card and groups
of up to 16 ports are supported on the 48x10G-T line card.
Media types
1 GbE optical
1 GbE copper SFP
10 GbE optical
10 G twinax copper
10Base-T copper
40 GbE optical
100 GbE CFP2 (SR10 or LR4) optical
TABLE 21
System architecture (Continued)
Feature
Description
TABLE 22
System size and weight
System
Size or weight
Width
43.99 cm (17.32 in.)
Height
66.22 cm (26.0 in.)
Depth
66.04 cm (26 in.)
Brocade VDX 8770-8
weight: (fully configured)
384-port configuration with eight line cards, including two
management modules, six switch fabric modules, four fans, eight
power supplies, and one cable management comb
165.56 kg (365 lb)
Empty chassis weight: (includes backplane, cables, bus-bars, power
distribution bus, chassis ID card)
•
No management modules
•
No switch fabric modules
•
No line cards
•
No power supplies
•
No fans
•
No cable management devices
61.24 kg (135 lb)
