System component weights

A

System component weights

Table 23

lists the weights of the compatible modules and FRUs.

Ethernet port supported optics

The Ethernet ports in the Brocade VDX 8770-8 support full duplex link speeds at 1, 10, 40, or 100
Gbps inbound and outbound.

Table 24

shows the optics supported in the line cards for the Brocade

VDX 8770-8.

TABLE 23

System component weights

FRU

Weight

Management module

2.25 kg (4.95 lb)

Switch fabric module

2.61 kg (5.75 lb)

48x1 GbE line card

5.85 kg (12.9 lb)

48x10 GbE line card

5.85 kg (12.9 lb)

48 x 10G-T line card

8.66 kg (19.1 lb)

12x 40 GbE line card

5.40 kg (11.9 lb)

27x 40 GbE line card

9.64 kg (21.25 lb)

6x 100 GbE line card

9.62 kg (21.2 lb)

Power supply

2.88 kg (6.35 lb)

Fan assembly

4.76 kg (10.5 lb)

Cable management comb

0.41 kg (0.90 lb)

Line card filler panel

1.72 kg (3.8 lb)

MM or SFM filler panel

.98 kg (2.15 lb)

Power supply filler panel

0.36 kg (0.8 lb)

TABLE 24

Supported optics

Speed

Wavelength

Fiber type

Cable core diameter
(microns)

Maximum cable distance

1 GbE

850

MMF

62.5

220 m (721.8 ft)

62.5

275 m (902.2 ft)

50

500 m (1640.4 ft)

50

550 m (1804.5 ft)

1310

MMF

62.5

550 m (1804.5 ft)

50

550 m (1804.5 ft)

50

550 m (1804.5 ft)

SMF

9

10 km (6.2 mi)

1 GbE Copper SFP

Copper

Cat5

Copper

100 m (328.1 ft)

10 GbE - USR

850

MMF

50

100 m (328.1 ft)
