<2. Specifications> 2-8
IM 11M10B01-01E
Desktop type with aspirator (OX400--A--)
With multi selector function
Rear
40 to 50
60 to 70
(Line connection :
in case of 1/4NPT)
(Line connection :
in case of 1/4NPT)
(Line connection :
in case of Rc1/4)
(Line connection :
in case of Rc1/4)
Bushing
Bushing
Aspirator
Aspirator
Connector
10 to 20
213
132
20
350 19.3
Sample gas inlet
Aspirator gas inlet ( Φ6)
Aspirator and sample gas outlet ( Φ8)
35.3
46
40
Hot air is discharged from the air outlet on the rear panel of the OX400.
Maintain at least 100 mm of free space around the OX400 to ensure
adequate ventilation.
Notes on installation
Unit: mm
